3
Installation
Installing Condensate Removal or Direct Vent Options
The dishwasher may be equipped with either a Condensate Removal Option or a Direct Vent
Option. These options ship separately from the dishwasher in their own containers. Separate
instructions are also included attached to the front of the dishwasher. These instructions may be
requested under the document part numbers listed below:
P/N 115107, Condensate Removal Option Installation Instructions
P/N 115109, Direct Vent Option Installation Instructions
Condensate Removal System Option
The condensate removal system removes dishwasher heat and water vapor at the end of the
dishwashing cycle recovering the normally exhausted heat and transferring the recovered heat
to the built-in booster heater which may eliminate the need for a dishwasher vent hood.
Direct Vent System Option
The direct vent system option removes dishwasher heat and water vapor directly into an exhaust
vent which may eliminate the need for a dishwasher vent hood.
NOTE
Complete installation instructions are located at the end of this service manual.
Condensate Removal Direct Vent
