12
Installation
Drain Connection - All Models
The drain water connection is a 2" slip-fit hose
connection and is located at the center-rear of
the machine base. It is a gravity drain.
1. The dishwasher drain is 2" O.D. hose
connection.
2. An optional drain water tempering kit
is available (consult the factory).
3. Drain water ow is controlled by an
automatic electrically operated drain valve.
4. The oor sink and/or drain plumbing
must be able to accommodate a
maximum drain ow rate of
20 US gpm / 17 Imp gpm / 76 Lpm.
Note: A Drain Water Tempering Kit Option is available to ensure the temperature of the
water entering the drain does not exceed 140ºF/60ºC (consult the factory).
Vent Fan Control for Standard Model Only
1. A vent fan control signal is provided on a terminal
block located inside the control cabinet.
The terminal locations are clearly marked.
2. The 120VAC signal is designed only to operate an
external vent fan contactor (supplied by others) and
is limited to .5 AMP maximum load and is available
when the dishwasher power switch is turned ON.
CAUTION:
Do not connect a vent fan motor to the signal
connection terminals.
The Vent Fan Control Signal is limited to
120VAC .5 Amp maximum load.
VENT FAN
120V .5A
RINSE AID
120V 1A
DETERGENT
120V 1A
Standard Model DH5000T installations using an overhead vent hood may require a vent fan
signal. This signal is supplied by the dishwasher control circuit.
The drain is a 2" slip-fit hose connection.
