37
Item Part Description Qty.
No. No.
Fill Piping Assembly with Booster - Standard Model and Direct Vent Option Model Only
1 102392 BUSHING, REDUCING, 3/4" NPT X 1/2" NPT BRASS 2
2 102438 ELBOW, STREET 1/2" NPT X 90° BRASS 1
3 111437 VALVE, SOLENOID 3/4" NPT HW 1
-- 114839 KIT, REPAIR VALVE 3/4" HW A/R
-- 111472 COIL, SOLENOID 3/4" 120V A/R
4 102651 NIPPLE, 3/4" NPT X 2" LG. BRASS A/R
5 115169 U-BOLT, 1/4-20 X 1¾" X 3" LG. (COMES WITH NUTS) 2
6 107550 VALVE, PRESSURE REGULATING 3/4" NPT BRONZE 1
7 102653 NIPPLE, 3/4" NPT X 4" LG. BRASS A/R
8 334775 BRACKET, DH5000 INLET PLUMBING SUPPORT 1
9 110768 STRAINER, LINE 3/4" NPT BRONZE FEMALE 1
10 102444 ELBOW, STREET 3/4" NPT X 90° BRASS 1
11 100184 NIPPLE, 3/4" NPT X CLOSE BRASS 1
12 100571 UNION, 3/4" NPT BRASS 1
13 115101 COUPLING, MALE 1/2" NPT X 1/2" 37° FLARE BRASS 1
To Next Page
