47
Item Part Description Qty.
No. No.
1 100500 BREAKER, VACUUM 1/2" NPT BRONZE 1
-- 900836 KIT, REPAIR VACUUM BREAKER 1/2" A/R
2 100209 NIPPLE, 1/2" NPT X CLOSE BRASS 3
3 102514 TEE, 1/2" NPT BRASS 4
4 114435 THERMISTER,10KΩ,36"LEAD 1
5 102388 BUSHING, REDUCING 1/2" NPT X 1/4" NPT BRASS 1
6 115101 COUPLING, MALE 1/2" NPT X 1/2" 37° FLARE BRASS 3
7 107065 ADAPTER, 1/4" OD X 1/4"MPT PLASTIC 1
8 107928 TUBING, 1/4" NATURAL P44 10 FT
9 334741 BRACKET, VACUUM BREAKER PIPING 1
10 419011 HOSE ASSY, 1/2" ID X 12" LG. FLARE JIC 1
11 101259 PLUG, 1/8" NPT SQ. HEAD, BRASS 1
12 103418 BUSHING, REDUCING 1/2" NPT X 1/8" NPT BRASS 1
13 115011 COUPLING, BULKHEAD 1/2 NPT BRASS 1
14 419015 HOSE ASSY., 1/2" ID X 5-1/2" LG. FLARE JIC 1
15 419010 HOSE ASSY., 1/2" ID X 58" LG. FLARE JIC 1
16 105994 CLAMP, HOSE M10 SST GEAR-TYPE 2
17 419008 HOSE ASSY., 1/2" ID X 22" LG. FLARE JIC 1
18 419001 HOSE ASSY., 1/2" ID X 12" LG. FLARE JIC 1
19 114902 GASKET, STANDPIPE WASH 2
20 334609 MANIFOLD, WELDMENT WASH CENTER 1
21 107340 CLAMP, HOUSE M28 SST GEAR-TYPE 2
22 115159 HOSE, DISCHARGE 1
23 109864 HUB SUPPORT, WASHARM 2
24 0507445 SPINDLE, WASHARM 2
25 107967 NUT GRIP, 1/4-20 W/NYLON INSERT 2
26 100736 BOLT, HEX HD., 1/4-20 X 3/4" SST 2
27 114154 BOLT, CARRIAGE, 1/4-20 X 1/2" SST 8
28 106026 WASHER, FLAT 1/4" SST 8
29 100003 HEX PLAIN NUT 1/4-20 SST 8
Wash/Rinse Spray Piping - Standard Model and Direct Vent Option Model
To Next Page
