59
Item Part Description Qty.
No. No.
Back Support and Hood Guide Assembly
1 334271 DUCT, EXHAUST WELDMENT 1
2 114904 GASKET, EXHAUST DUCT 1
3 100073 SCREW, TRUSS HEAD, 1/4-20 X 1/2" SST 19
4 334657 BRACKET STOP, HANDLE 2
5 334612 SUPPORT WELDMENT, BACK 1
6 100003 NUT, PLAIN 1/4-20 SST 8
7 114154 BOLT, CARRIAGE 1/4-20 X 1/2" LG. SST 4
8 334776 BRACKET, SPRING MOUNT 1
9 334685 TOP, HOOD WELDMENT 1
10 334227 DEFLECTOR, EXHAUST 1
11 114886 GUIDE, HOOD 2
12 114866 SCREW, 1/4-20 X 1-1/2" FILLISTER HEAD SST 18
13 334621 BAFFLE, DEFLECTOR HOOD 2
14 334685 TOP, HOOD WELDMENT 1
15 334644 UPRIGHT, WELDMENT LH 1
16 334645 UPRIGHT, WELDMENT RH 1
17 106482 WASHER, LOCK 1/4" SPLIT SST 12
18 106481 NUT, ACORN PLAIN 1/4-20 SST 20
19 100735 BOLT, HEX HD. 1/4-20 X 5/8" SST 4
20 106026 WASHER, FLAT 1/4" SST 4
21 419014 HOSE ASSY. WATER IN 22" LG. 1
22 115101 COUPLING, MALE 1/2" NPT X 1/2 37° FLARE BRASS 1
23 102392 BUSHING, REDUCING 3/4" NPT X 1/2" NPT BRASS 1
24 115026 COUPLING, BULKHEAD 3/4" NPT BRASS 1
To Next Page
