61
Item Part Description Qty.
No. No.
1 334463 BRACKET, ENCLOSURE MOUNT (MACHINE MOUNT) 1
2 100779 SCREW, 1/4-20 X 5/8" TRUSS HEAD SST 4
3 106026 WASHER, FLAT 1/4" SST 4
4 106482 WASHER, SPLIT LOCK 1/4" SST 4
5 100003 NUT, PLAIN 1/4-20 SST 4
6 114973 ENCLOSURE 11" X 7.5" X 4" 1
7 114974 PANEL, INNER 1
8 100212 SCREW, 1/4-20 X 3/4" TRUSS HEAD SST 4
9 108122 CONTACTOR, 12A 1
10 111068 RELAY, 2PDT, 120VAC 3A 2
11 111036 SOCKET, RELAY 2
12 114980 RELAY, LATCH DPDT, 120VAC 3A 1
13 114645 SOCKET, RELAY 1
14 114981 TIMER, INTERVAL, ADJUSTABLE 1-90 SEC., 120VAC 2
15 334473 BRACKET, ENCLOSURE MOUNT (WALL MOUNT) 2
Condensate Removal Option and Direct Vent Option - Electrical Control Box
