65
Item Part Description Qty.
No. No.
Condensate Removal Option - Shroud, Fan, and Coil
1 334680 BOX WELDMENT, CONDENSATE REMOVAL 1
2 114988 SCREW, FILLISTER HEAD, 8-32 X 2" SST 8
3 114976 FAN, 85 CFM AXIAL, 85-265VAC 2
4 334552 PLENUM TOP, COIL 1
5 334475 SHROUD, COIL 1
6 114931 COIL ASSEMBLY 1
7 334374 PANEL, REAR CONDENSATE REMOVAL 1
8 102438 ELBOW, STREET 1/2" NPT X 90° BRASS 2
9 115101 COUPLING, MALE 1/2" NPT X 1/2", 37° FLARE, JIC BRASS 3
10 334476 PAN, COIL DRAIN WELDMENT 1
11 419004 HOSE ASSY., 1/2" ID X 9¼" LG. FLARE JIC 1
12 115026 COUPLING, BULKHEAD, 3/4" NPT BRASS 1
13 419012 HOSE ASSY., 1/2" ID X 60" LG. FLARE JIC 1
14 419005 HOSE ASSY., 1/2" ID X 36" LG. FLARE JIC 1
15 419012 HOSE ASSY., 1/2" ID X 80" LG. FLARE JIC 1
16 105994 CLAMP, HOSE M10 SST, GEAR-TYPE 1
17 419015 HOSE ASSY., 1/2" ID X 6-1/2" LG. FLARE JIC 1
18 102514 TEE, 1/2" NPT BRASS 1
19 100209 NIPPLE, 1/2" NPT X CLOSE, BRASS 1
20 115011 COULPLING, BULKHEAD, 1/2" NPT BRASS 1
21 103418 BUSHING, REDUCING 1/2" NPT X 1/8" NPT BRASS 1
22 101259 PLUG, 1/8" NPT SQ. HEAD, BRASS 1
To Next Page
