Temperature Display Adjustment - (For Service Technicians Only)

Temperature Display Adjustment - For Service Technicians Only (continued)

Adjusting the Temperature Displays (continued)

1. The set-point determines the way the semi-circular bar displays temperature. For

example, if the set-point is 70ºF/21ºC, then the bar will indicate yellow beginning at zero

up to 70 and change to green from 70 and beyond.

2. There are six set-point values: 70, 120, 150, 160, 165 and 180ºF or 21, 49, 65, 71, 74

and 82ºC depending on the position of the ºF/ºC unit selector switch.

3. Locate the CHECK button on the rear of the display board. It is located in the top center

of the board.

4. Push and hold the CHECK button while observing the front of the display board. The

washdisplayashesitscurrentset-pointwhiletherinsedisplayisblank.

5. Release the CHECK button and both displays indicate actual temperatures.

6. PushandHoldtheCHECKbutton,thewashdisplayashesitsset-pointandtherinseis

blank. Continue to hold the CHECK button and the wash display blanks out and the rinse

displayashesitsset-point.

7. Release the CHECK button and the displays indicate actual temperatures.

Checking Display Set-points

Changing Display Set-points

1. Push and hold the CHECK button while observing the front of the display board.

Assoonasthewashdisplayashesitscurrentset-point,(70intheexamplebelow),

immediatelyreleasetheCHECKbuttonwhen70ashes;pushtheCHECKbutton

again— 120 is displayed.

2. Push and release the CHECK button again and 150 is displayed. Push and release

advances the set-point displayed from 70-180.

3. If the desired set-point is 150 and the current set-point is 70, then you would push and

release the CHECK button two times until 150 is displayed.

4. When150isdisplayedholdtheCHECKbutton.150willashindicatingthatthenew

set-point value of 150 is set.

5. If you go past the desired set-point, then start over. There is a certain amount of timing

and coordination between pushing the CHECK button and observing the display for the

desired set-point. Repeat steps 1-5 until the desired set-point is entered.

Wash Display
