203-01-5 Disc Type Brake of the Front Wheel 203-01-5
Disassembly and Installation
REMOVAL AND INSTALLATION
Brake Disc (12 234 0)
Special Tool
206-005 (12-014)
Piston tractor of the brake
distributing pump
206-005 (12-014)
Name
Model
Brake fluid
HZY4
Disassembly
Warning: If braking fluid is spattered on the
painted surface, use clean water to rinse the
braking fluid immediately.
1. Loosen the tyre nuts.
2. Hoist the automobile. See Section 100-02 for
relevant information.
3. Disassemble the wheel.
4. Remove the brake caliper.
1. Disassemble the lower bolt of the brake caliper.
2. Rotate the brake caliper upwards.
5. Disassemble the brake disc.
Installation
1.
Warning: when tightly pressing the piston
of the brake distributing pump into the
piston cylinder, braking fluid may puff up
from the master brake cylinder.
Use a special tool to compress the piston of the
brake distributing pump.
BENNI MINI
