204-01-5 Electric Power Assistant Steering Column
204-01-5
Controller instruction and inspection
BENNI·MINI
1. Controller Maintenance Attention Issues
1. Remove the controller harness and make sure the
controller in a open status, please shut down the vehicle
Controller installation bolts
and the power when removing the connector
2. Disassemble and installation of the EPS controller
1） Take off the battery negative harness
2） Loose the installation bolts of EPS controller
3） Disassemble the connector
4） Disassemble the EPS controller
Installation:
The installation process is opposite to the disassembly process
