Changan BENNI MINI 2011 - Steering System Diagnosis and Test

204-00-4 Steering System-General 204-00-4
Diagnose and test
CHANA·BENNI MINI
DIAGNOSIS AND TESTING
Steering System
Working Principles
The rotating motion of the steering wheel is transmitted
to the steering mechanism through the steering column.
The steering mechanism can convert the rotating
motion into the straight line motion though the gear
rack in the steering mechanism. The straight line
motion is transmitted to the steering knuckle of the
wheel through the steering tie rod and the external
connector of the tie rod.
The steering oil pressure is applied to the steering
mechanism through the power steering pump. When
the steering wheel is rotated, the power steering oil
shall open valve at one end of the double-way piston
according to the rotating direction of the steering wheel,
the piston is pushed to be moved by the oil pressure, to
supply the auxiliary power required in the steering.
Failure Phenomenon Table
Check and Confirmation
1. Check the problems of the customer
2. Inspect the obvious-damaged parts visually, as
shown in the following table:
visual inspection table
Mechanical Aspect
Electric Appliance
Aspect
– tire and pressure
– wheel and tire
– Controller harness
– Motor
3. If the reason of the problem is obvious, the problem
should be tried to be solved before the next operation is
performed.
4. If the reason of the problem is not obvious, the
reason should be found out according the failure
phenomenon.
malfunction phenomenon
Possible Reasons Measures
The steering is difficult or easy • speed signal lost or interference
• check speed signal ,refer to
204-04
• engine signal lost or interference
• check engine signal ,refer to
204-04
• power bad connection check power ,refer to204-04
• the suspension ball joint
inseparable
• test the suspension ball, refer to
201-00
• steering mechanism damage •Replace the steering mechanism
• steering column damage
•Test the steering connect parts,
refer to ”steering connection
test “part
• steering motor damage
• Replace the power assistant
motor ,refer to the 204-01
The steering is not sensitive (when
the steering wheel is rotated, its
direction is not changed)
• tie rod ball damage
• replace the tie rod if
necessary, refer to the 201-01
• front suspension bush damage
•inspect or replace, refer to
201-01
• suspension ball damage
• check the suspension ball joint,
refer to the 201-00
• steering mechanism anti-dust
cover damage
•inspect or replace it if necessary,
refer to the 204-02
