203-02-2 Drum Type Brake 203-02-2
Specification
BENNI MINI
Grease, Oil Fluid, Sealant and Bonding Agent
Name
Name Model
Braking Fluid HZY 4
Specifications of Drum Type Brake
mm
Diameter of the new brake drum 180
Disabled diameter of the brake drum 182
Width of the brake shoe 30
Hole diameter of the brake distributing pump 17.46（ABS）15.87
（NO ABS）
Thickness of the leading shoe lining of the new brake 4.5
Disabled thickness of the lining sheet of the brake shoe 1.5
* When the diameter of the braking drum is up to the disabled standard, the brake drum should be replaced. When
the brake drum is not up to the disabled standard, the brake drum should be processed with caution.
T
orque Specifications
Descriptions
Nm
Wheel hub fixing nut 220
Tyre nuts 85
Fixing bolt of the brake distributing pump 10
Connector of the barking hose 15
