Chappee Initia SUPER 2.24 FF - Page 43

INITIA SUPER CHAPPEE
CPB43224X270-2 INITIA SUP.2.24CF CHAPPEE
CPB43228X270-2 INITIA SUP.2.28CF CHAPPEE
CPB43524X260-2 INITIA SUP.1.24FF CHAPPEE
CPB435243280 - INITIA SUPER 1.24 FF VM
CPB435283280 - INITIA SUPER 1.31 FF VM
CPB435283280 - INITIA SUPER 1.28 FF VM
CPB43624X260-2 INITIA SUP.2.24 FF CHAPPEE
CPB43631X260-3 INITIA SUP.2.31FF CHAPPEE
X=1->LPG / X=3->NATURAL GAS
Pos Description Code
Tab.
01
Tab.
02
Tab.
03
Tab.
04
Tab.
04
Tab.
04
Tab.
05
Tab.
06
From serial
number
To serial
number
Inter-
changeable
1 LATERAL REAR SUPPORT H=763 5653140
l l l l l l
1 LATERAL REAR SUPPORT H=803 5653150
l l
2 LEFT PANEL ASSEMBLY H=763 5653630
l l l l l l
2 LATERAL PANEL H=803 5112030
l l
3 RIGH PANEL ASSEMBLY H=763 5653620
l l l l l l
4 FRONTAL PANEL ASSEMBLY I 5655190
l l
4 FRONTAL PANEL ASSEMBLY FI 5111940
l l l l l l
5 UPPER TRAVERSE 5110290
l l l l l l l l
6 LOWER TRAVERSE 5109640
l l l l l l l l
7 FRONTAL TRAVERSE 5112020
l l
8 PRESSURE SWITCH PIPE L=270 5408080
l l l l l l
9 SUCTION RESTRICTOR D.80 5108700
l l l l l l
10 FLUE FLANGE 5207060
l l l l l l
11 FLANGE GASKET 5407890
l l l l l l
12 SUCTION CAP 5108690
l l l l l l
13 SUCTION CAP GASKET 5407400
l l l l l l
15 JOINT ASSEMBLY (with gasket and screws) 600530
l l l l l l
17 CONVEYOR BEND 5211090
l l l l l l
18 FLUE PLASTIC VENTURI 5407050
l l l l l l
21 GASKET 6,1X12X1,5 WRC (ex 5402050) 5402080
l l l l l l l l
22 FAN 1 SPEED (MVL) 5653850
l l l
22 FAN 1 SPEED (MVL) 75W 5655730
l l l
23 FAN PRESSURE SWITCH ASSEMBLY 618470
l l l l l l
23 FAN PRESSURE SWITCH (TRIDELTA) 5655120
l l l l l l
24 COMPENSATION PIPE L=150 5407930
l l l l l l
25 CONVEYOR ASSEMBLY 5653170
l l l
25 CONVEYOR ASSEMBLY 5653180
l l l
27 COMBUSTION CHAMBER ASSEMBLY (ATM) 5653760
l
27 COMBUSTION CHAMBER ASSEMBLY (FF) 5653780
l l l
27 COMBUSTION CHAMBER ASSEMBLY (FF) 5655480
l l l
27 COMBUSTION CHAMBER ASSEMBLY (28ATM) 5655510
l
28 LATERAL INSULATING PANEL 5213160
l l l l l
28 LATERAL INSULATING PANEL 5213190
l l l
29 REAR INSULATING PANEL 5213240
l
29 REAR INSULATING PANEL 5213290
l l l l l l l
30 FRONTAL INSULATING PANEL (FF) 5213340
l l l l l l
30 FRONTAL INSULATING PANEL (ATM) 5213320
l
30 FRONTAL INSULATING PANEL 5213310
l
31 COMB. CHAMBER PANEL 5111840
l l l
31 COMB. CHAMBER PANEL 5111850
l l l
31 COMB. CHAMBER FRONT PANEL 5108030
l
31 COMB. CHAMBER FRONT PANEL 5108500
l
32 PRIMARY EXCHANGER WITH CLIPS 5632470
l l l l
