Chappee Initia SUPER 2.24 FF - Page 46

INITIA SUPER CHAPPEE
CPB43224X270-2 INITIA SUP.2.24CF CHAPPEE
CPB43228X270-2 INITIA SUP.2.28CF CHAPPEE
CPB43524X260-2 INITIA SUP.1.24FF CHAPPEE
CPB435243280 - INITIA SUPER 1.24 FF VM
CPB435283280 - INITIA SUPER 1.31 FF VM
CPB435283280 - INITIA SUPER 1.28 FF VM
CPB43624X260-2 INITIA SUP.2.24 FF CHAPPEE
CPB43631X260-3 INITIA SUP.2.31FF CHAPPEE
X=1->LPG / X=3->NATURAL GAS
Pos Description Code
Tab.
01
Tab.
02
Tab.
03
Tab.
04
Tab.
04
Tab.
04
Tab.
05
Tab.
06
From serial
number
To serial
number
Inter-
changeable
117 SANITARY PLATE ASSEMBLY 5646180
l l l l
118 CONIC SPRING 8380520
l l l l l l l
119 HEATING PLATE ASSEMBLY 5646170
l l l l
119 HEATING PLATE ASSEMBLY 605760
l l l
120 SANITARY PLUG ASSEMBLY 5646190
l l l l
120 SANITARY PLUG ASSEMBLY 600750
l l l
121 SCREW M5X10 8101410
l l l l
122 O-RING 23,47X2,62 5405370
l l l l l
123 SCREW M5X13 8101440
l l l l
124 SPRING 8380540
l l l l
125 MICROSWITCH OPERATING PIN 5630260
l l l l
126 DHW PRESSOSTAT PLATE ASSEMBLY 5630270
l l l l
127 DHW PRESSOSTAT DIAPHRAGM 5405330
l l l l
128 O-RING 2,6X1,9 5405400
l l l l
129 PIN GUIDE 5207860
l l l l
130 MICROSWITCH WITH LEVER ASSEMBLY 5625770
l l l l l l l l
131 NTC SENSOR (alt. 9950930) 8433090
l l l l l l l l
B304
131 NTC SENSOR 8434820
l l l l l l l l
B304 YES
132 NTC SENSOR GASKET 5402830
l l l l
135 LIMIT THERMOSTAT 105°C 9950760
l l l l l l l l
136 EXCHANGER/3 PORT VALVE PIPE 5655460
l l l
136 EXCHANGER/3 PORT VALVE PIPE 5655560
l
136 EXCHANGER/3 PORT VALVE PIPE 5655640
l
136 EXCHANGER/3 PORT VALVE PIPE 5653240
l l l
137 CONNECTING ELEMENT (GAS VALVE/RAMP) 5210700
l l l l l l l l
138 O-RING 22,22X2,62 5402010
l l l l l l l l
139 GAS VALVE INLET CONNECTION 5210630
l l l l l l l l
140 GAS VALVE (HONEYWELL VK 4105 M) 5665210
l l l l l l l l
147 CONNECTION TRAVERSE 5653160
l l l l l l l l
151 ELECTRIC BOX REAR COVER 5407650
l l l l l l l l
152 PRINTED CONTROL PANEL -INITIA SUPER2.24CF- 5669620
l
152 PRINTED CONTROL PANEL -INITIA SUPER2.28CF- 5669630
l
152 PRINTED CONTROL PANEL -INITIA SUPER1.24FF- 5656980
l
152 PRINTED CONTROL PANEL -INITIA SUPER2.24FF- 5665700
l
152 PRINTED CONTROL PANEL -INITIA SUPER2.31FF- 5665710
l
152
PRINTED CONTROL PANEL -INITIA SUPER1.24FF VM-
5673730
l
152
PRINTED CONTROL PANEL -INITIA SUPER1.28FF VM-
5673740
l
152
PRINTED CONTROL PANEL -INITIA SUPER1.31FF VM-
5682740
l
153 TERMINAL BOARD COVER 5407660
l l l l l l l l
154 P.C.B. (SIT) 5654950
l l l l l
YES
154 P.C.B. (Honeywell) 5655990
l l l l l
B437 YES
154 P.C.B. OMNI 2000 (HONEYWELL/INECO) 5657840
l l l
154 P.C.B. LMU33-SIEMENS 5669060
l l l
