Chappee Initia SUPER 2.24 FF - Page 48

INITIA SUPER CHAPPEE
CPB43224X270-2 INITIA SUP.2.24CF CHAPPEE
CPB43228X270-2 INITIA SUP.2.28CF CHAPPEE
CPB43524X260-2 INITIA SUP.1.24FF CHAPPEE
CPB435243280 - INITIA SUPER 1.24 FF VM
CPB435283280 - INITIA SUPER 1.31 FF VM
CPB435283280 - INITIA SUPER 1.28 FF VM
CPB43624X260-2 INITIA SUP.2.24 FF CHAPPEE
CPB43631X260-3 INITIA SUP.2.31FF CHAPPEE
X=1->LPG / X=3->NATURAL GAS
Pos Description Code
Tab.
01
Tab.
02
Tab.
03
Tab.
04
Tab.
04
Tab.
04
Tab.
05
Tab.
06
From serial
number
To serial
number
Inter-
changeable
473 NUT G1/2 9950300
l l l l l l l l
474 NIPPLE G1/2 5627980
l l l l l l l l
475 COLD WATER PIPE 5628000
l l l l l l l l
478 SANITARY FILTER 5110040
l l l l l l l l
479 O-RING 20,35X1,78 5405190
l l l l l l l l
480 GAS PIPE 5628010
l l l l l l l l
481 NUT G3/4 5628030
l l l l l l l l
490 COLD WATER TAP WITH FILTER 5625970
l l l l l l l l
491 PLUG/FILTER ASSEMBLY 5637070
l l l l l l l l
493 FILLING KNOB ASSEMBLY 605660
l l l l
496 O-RING 2062 400020
l l l l l l l l
510 DHW PADDLE ASSEMBLY 600760
l l l
511 O-RING 17,86X2,62 5404600
l l l l l l l l
516 PIN 5210670
l l l l l l
517 PIPE FIXING ELEMENT 5407840
l l l l l l l l
518 CONTROL PANEL PIN 5107180
l l l l l l l l
519 NEON GLASS 5407780
l l l l l l l l
520 FLAP 5112050
l l l l l l
521 FLAP FIXING SPRING 8380730
l l l l l l
522 IGNITER SUPPORT 5655180
l l l l l l l l
525 NAC CONNECTOR (SIT) 8419060
l l l l l l l l
526 SUCTION ADJUSTING CHOKE 5408020
l l l
527 HOLE PLATE 5408210
l l l l
528 NTC SENSOR 8434590
l l l l
686 NO RETURN VALVE BY-PASS 5663020
l l l
691 MODULATOR ASSEMBLY -VK4105M- 5665230
l l l l l l l l
B240
LOW VOLTAGE COMP. WIRING (VK4105A) 5655570
l l l l
B240
LOW VOLTAGE COMP. WIRING (SIT & VK4105M) 5655580
l l l l
LOW VOLTAGE COMP. WIRING (VK4105A) 5655110
l l l l
B240
LOW VOLTAGE COMP. WIRING (SIT & VK4105M) 5655100
l l l l
TERMINAL BOARD WIRING 8418950
l l l l l l l l
FLUE/LIMIT THERMOSTAT WIRING 8419140
l l
FAN/AIR PRESSURE SWITCH/LIMIT TH. WIRING 8419160
l l l l l l
IGNITER/GAS VALVE WIRING (Honeywell) 8419150
l l l l l l l l
PUMP/SELECTOR WIRING 8419130
l l l l l l l l
POWER SUPPLY CABLE 8414620
l l l l l l l l
TIMER CONNECTOR 8418860
l l l l l l l l
