Chappee Initia SUPER 2.31 FF - Page 45

INITIA SUPER CHAPPEE
CPB43224X270-2 INITIA SUP.2.24CF CHAPPEE
CPB43228X270-2 INITIA SUP.2.28CF CHAPPEE
CPB43524X260-2 INITIA SUP.1.24FF CHAPPEE
CPB435243280 - INITIA SUPER 1.24 FF VM
CPB435283280 - INITIA SUPER 1.31 FF VM
CPB435283280 - INITIA SUPER 1.28 FF VM
CPB43624X260-2 INITIA SUP.2.24 FF CHAPPEE
CPB43631X260-3 INITIA SUP.2.31FF CHAPPEE
X=1->LPG / X=3->NATURAL GAS
Pos Description Code
Tab.
01
Tab.
02
Tab.
03
Tab.
04
Tab.
04
Tab.
04
Tab.
05
Tab.
06
From serial
number
To serial
number
Inter-
changeable
72 PUMP UP 15-60 AO (GRUNDFOS) 5655620
l l l l
73 AIR VENT VALVE (GRUNDFOS) 607290
l l l l l l l l
74 O-RING 14X1,78 EP 5406360
l l l l l l l l
75 GASKET (WATER PIPE/SEALED CHAMBER) 5404670
l l l l l l
76 DHW PLATE EXCHANGER (12 plates) alt. 9951040 5653660
l l
76 DHW PLATE EXCHANGER (14 plates) 5653680
l
76 DHW PLATE EXCHANGER (16 plates) alt. 9951090 5655780
l
77 DHW EXCHANGER GASKET 5404520
l l l l
80 HYDRAULIC INLET GROUP 5655650
l l l l
80 HYDRAULIC INLET GROUP WITH FILLING TAP 5653550
l l l l
81 FILTER AND VENTURI ASSEMBLY 607240
l l l l
82 HYDRAULIC VENTURI ASSEMBLY 5630170
l l l l
84 FILTER D. 13,5 5111180
l l l l
85 O-RING 20,63X2,62 5405350
l l l l
87 PUMP CONNECTING ELEMENT 5210710
l l l l l l l l
90 FILLING TAP ASSEMBLY 5630180
l l l l
91 DRAINING TAP (alt. 9951120) 5652030
l l l l l l l l
92 HYDRAULIC SAFETY VALVE 3 bar WITH O-RING 5653690
l l l l l l l l
96 PRESSURE PIPE (POSITIVE) 5653280
l l l l
97 PRESSURE PIPE (NEGATIVE) 5653270
l l l l
98 BY-PASS PIPE ASSEMBLY 5653260
l l l l
98 BY-PASS PIPE ASSEMBLY 5628240
l
98 BY-PASS PIPE ASSEMBLY 5664370
l l l
99 BY-PASS PIPE FIXING CLIP 5108130
l l l l l l l l
100 O-RING 13,94X2,62X EPDM 5406630
l l l l l l l l
101 3 P.VALVE/PRESSOST./SENSOR ASS. 5653590
l l l l
102 BY PASS/PRESSOST. 5628230
l
102 3 PORT VALVE/PRESSOSTAT ASSEMBLY 607250
l l l l
102 3 PORT VALVE 5658690
l l l
103 SENSOR ASSEMBLY (DHW PRESSOSTAT) 5629950
l l l l
104 SANITARY OUTLET CONNECTION 5653840
l l l l
106 SCREW M5X12 8101430
l l l l
107 PIN GUIDE ASSEMBLY 5630250
l l l l l l l l
108 SCREW M4X12 8101420
l l l l l l l l
109 GASKET 10X14X1,5 5207810
l l l l l l l l
110 SPRING 8380530
l l l l l l l l
111 PRESSOSTAT PLATE ASSEMBLY 5630240
l l l l l l l l
112 3 PORT VALVE DIAPHRAGM 5405320
l l l l
112 DIAPHRAGM 5405960
l l l l
113 BY-PASS ASSEMBLY 5630190
l l l l l l l
113 BY-PASS ASSEMBLY 5635220
l
114 O-RING 26,64X2,62 5403820
l l l l
115 BY-PASS PLUG ASSEMBLY 5645660
l l l l l l l l
