DIGITAL ELECTRIC VERTICAL SMOKER 725
Use only with GFI (Ground Fault Interrupter) protected circuit.
Use sólo con GFI (interruptor de fallo de tierra) del circuito protegido.
Utiliser uniquement avec GFI (Interruptor de défaut de tierra) circuit protégé.
FOR OUTDOOR USE ONLY
POUR USAGE EN MILIEU EXTÉRIEUR UNIQUEMENT
ESTE JUEGO SÓLO SE PUEDE USAR EXTERIORS
If you have questions or need assistance
during assembly, please call 1-888-430-7870.
Si vous avez des questions ou besoin d´aide
pendant l’assemblage, S’il vous plaît appelez
1-888-430-7870
Si tiene alguna pregunta o si Necesita
ayuda durante el Ensamblado, llámenos Al
1-888-430-7870
Serial number | Numéro de série | Número de serie
Date purchased | Date d’chat | Fecha de compra
See rating Label on grill for serial number.
El número de serie se encuentra en la etiqueta de
especificaciones de la parrilla.
Ce numéro se trouve sur l´étiquette signalétique sur
i´appareil.
17202002 17202004
®
FUMOIR ÉLECTRIQUE NUMÉRIQUE VERTICAL 725
®
AHUMADOR DIGITAL ELÉCTRICO VERTICAL 725
17202002
17202004

Table of Contents

Questions and Answers

  • R
    Robin DelgadoAug 18, 2025
    Why is my Char-Broil Smoker not heating up?
    • T
      Thomas WilliamsAug 18, 2025
      If your Char-Broil Smoker isn't heating, first ensure it's properly plugged in. You should hear a beep when it's connected. If it's plugged in, turn the smoker off and unplug it from the outlet. Check your household circuit breakers or GFCI and reset or replace if necessary, using a GFCI rated for 15 amperes or more. Test the outlet with another working appliance. If it still doesn't work, try a different outlet on a different circuit. As additional steps, unplug and reconnect the thermostat and control panel connections. If problems persist, the thermostat, control panel display or power board kits may need replacement. Refer to the online Electrical Replacement Manual for detailed instructions.
  • E
    Elizabeth SmithAug 20, 2025
    Why does my Char-Broil Smoker keep tripping the circuit breaker?
    • J
      Jennifer LopezAug 20, 2025
      If the circuit breaker trips or the fuse blows when using your Char-Broil Smoker, avoid using other electrical appliances on the same circuit. Moisture in the controller or electrical connections can also cause this, so keep all connections dry and do not use the smoker in the rain. You can also try turning the smoker OFF and unplugging it from the outlet. Unplug and reconnect the thermostat connections and if problems persist, the thermostat kit or power supply cord kit may need replacement. Refer to the online Electrical Replacement Manual for detailed instructions.
  • S
    Sherry NicholsAug 23, 2025
    How to prevent flare-ups in my Char-Broil 17202004 Smokers?
    • B
      Bethany JohnsonAug 23, 2025
      Flare-ups in your Char-Broil Smoker can occur due to excess fat in the meat. Trim the fat before cooking to help prevent this. High cooking temperatures can also cause flare-ups, so adjust the temperature as needed. Lastly, grease buildup can ignite, so regularly clean the smoker, cooking grates, drip pan, grease tray, and water pan.
  • W
    Wayne GilbertAug 26, 2025
    What to do if my Char-Broil Smoker has no display?
    • A
      Anthony DawsonAug 26, 2025
      If there is no display on your Char-Broil Smoker, turn the smoker OFF and unplug it from the outlet. Unplug the smoker and plug it back into the outlet; a beep should sound when plugged in. Also, unplug and reconnect the thermostat and control panel connections. The thermostat, control panel display or power board kits may need replacement. Refer to the online Electrical Replacement Manual for instructions.
  • A
    Angela MurrayAug 28, 2025
    What to do if my Char-Broil Smoker has a persistent grease fire?
    • G
      Gregory MyersAug 28, 2025
      If you have a persistent grease fire in your Char-Broil Smoker, turn the smoker OFF and unplug it from the outlet. Keep the door open and let the fire burn out. Never apply water to the fire to prevent personal injury. After the smoker cools, clean the smoker, cooking grates, drip pan, grease tray, and water pan.
  • E
    emartinezAug 30, 2025
    How to fix unresponsive remote control on Char-Broil 17202004?
    • A
      ashleyrossAug 30, 2025
      To resolve an unresponsive remote control with your Char-Broil Smoker, reset the remote control: First, on the main control, press and hold the Power button for 3 seconds until it beeps. Then, on the remote control, press the Power button twice. The remote control is now synced to the smoker, indicated by the ** symbol.
  • D
    Daniel HernandezSep 1, 2025
    What does Err2 mean on my Char-Broil Smoker?
    • T
      timothygonzalezSep 1, 2025
      If you see 'Err2' on your Char-Broil Smoker, turn the Smoker OFF and unplug it from the outlet. Check or replace components in the following order: thermostat kit, control panel display kit and power board kit.
  • K
    Krystal WilliamsSep 4, 2025
    What does Err1 mean on my Char-Broil Smoker?
    • Z
      zachary14Sep 4, 2025
      If you see 'Err1' on your Char-Broil Smoker, turn the Smoker OFF and unplug it from the outlet. Replace the Thermostat Kit.
  • M
    Mark MartinezSep 6, 2025
    What does Err3 mean on my Char-Broil Smoker?
    • J
      Joshua SimpsonSep 7, 2025
      If you see 'Err3' on your Char-Broil Smoker, turn the Smoker OFF and unplug it from the outlet. Check or replace the meat probe, meat probe housing or control panel display kit.
  • K
    Kristin Rice DVMSep 9, 2025
    What does Err4 mean on my Char-Broil Smoker?
    • A
      Alexandra MurraySep 9, 2025
      If you see 'Err4' on your Char-Broil Smoker, turn the Smoker OFF and unplug it from the outlet. Check or replace the meat probe and the meat probe housing.

Summary

IMPORTANT SAFEGUARDS

Safety Symbols

General Safety

Extension Cord Use and Safety

Guidelines for safely using extension cords with the smoker, including types and lengths.

Ground Fault Interrupter

Requirement and importance of using GFI outlets for outdoor electrical circuits.

Use and Care of Your Smoker

Food Safety

How To Tell If Meat Is Cooked Thoroughly

Control Panel Operating Instructions

Seasoning Your Smoker

Cooking with your Smoker

Setting the Preheat Cycle

Step-by-step guide for initiating and completing the smoker's preheat cycle.

Using the Temp Button

Using the Time Button

Remote Control Operating Instructions

ASSEMBLY

Troubleshooting

Error Codes

Char-Broil 17202004 Specifications

General IconGeneral
TypeElectric Smoker
Model Number17202004
BrandChar-Broil
Voltage120V
Number of Racks4
Construction MaterialSteel
Digital ControlYes
Built-in ThermometerYes
WheelsYes
Temperature ControlDigital
Wood Chip Capacity1.5 cups
