ASSEMBLY / ASSEMBLAGE / ASAMBLEA
Page 33
CHARBROIL.COM
PARTS LIST
Key Qty Description
1 1 TOP LID
2 1 LOGO PLATE F/ LID
3 2 RUBBER BUMPER, W/ HOLE, F/ TOP LID
4 1 HANDLE F/ LID
5 1 THERMOMETER
6 1 BEZEL, F/ THERMOMETER
7 1 TOP LID HARDWARE
8 1 FIREBOX
9 4 BURNER BRACE
10 4 MAIN BURNER
11 1 ELECTRODE, F/ MAIN BURNER
12 3 CARRY OVER TUBE
13 1 CONTROL PANEL, MAIN
14 1 ELECTRONIC IGNITION MODULE
15 1 BUTTON, F/ IGNITION MODULE
16 1 HOSE VALVE REGULATOR ASSEMBLY
17 4 BEZEL F/ CONTROL KNOB
18 5 CONTROL KNOB
19 1 RIGHT SIDE SHELF
20 1 FASCIA, F/ RIGHT SIDE SHELF
21 1 SIDEBURNER SHELF
22 1 FASCIA, F/ SB SHELF
23 1 SHELF SUPPORT, RIGHT
24 1 SHELF SUPPORT, LEFT
25 1 LID, F/ SIDEBURNER
26 1 DRIP PAN, F/ SIDEBURNER
27 1 GRATE, F/ SIDEBURNER
28 1 SIDEBURNER
29 1 ELECTRODE, F/ SIDEBURNER
30 1 IGNITOR WIRE, F/ SIDEBURNER
31 4 HEAT TENT
32 2 COOKING GRATE T120
33 1 COOKING GRATE T180
34 1 WARMING RACK
35 1 LEFT FRONT LEG
Key Qty Description
36 1 LEFT BACK LEG
37 2 CART BRACE, SIDE, UPPER
38 1 LOWER CART BRACE, LEFT
39 4 LEG CAP
40 1 RIGHT FRONT LEG
41 1 RIGHT BACK LEG
42 1 LOWER CART BRACE, RIGHT
43 1 SIDE BAR, F/ CART
44 1 TOP FRONT PANEL
45 1 LOWER FRONT PANEL
46 2 CART BRACE, REAR
47 1 TANK EXCLUSION WIRE
48 1 TANK RETAINER WIRE
49 2 WHEEL
50 2 AXLE ROD
51 2 LEG EXTENDER
52 1 GREASE TRAY
53 1 GREASE PAN
54 2 GREASE TRAY BRACKET
55 1 MATCH HOLDER
56 1 SHIELD, F/ TANK
57 1 BEZEL F/ SB CONTROL KNOB
NOT Pictured
… 1 PRODUCT GUIDE, ENGLISH, FRENCH, SPANISH
… 1 HARDWARE PACK
… 1 VENTURI CLIP F/ SB
