Char-Broil 463365021 - Ignition Module and Controls

CHARBROIL.COM
Page 46
ASSEMBLY / ASSEMBLAGE / ASAMBLEA
16
17
2ND
2ND
1ST
1ST
#14
#15
#16
#57
#18
#14
#15
+
-
Remove screws
Enlevez les vis
Retire los tornillos
Secure using screws that were removed from sideburner valve bracket.
Fixez le tout au moyen des vis enlevées du support de valve du brûleur latéral.
Fíjelo con los tornillos que retiró del soporte de la válvula del quemador lateral.
