Char-Broil Basic C58G4 - Page 23

14
15
Left door
Right door
Hinge pin
on bottom
of door
Top of
door
PRESS
Insert hinge pin on bottom of doors into hole in bottom shelf. Press upper hinge pin in front brace, align hinge hole on top of
door, and release hinge pin into door.
Flame tamer
Install flame tamers by sliding one end of each flame tamer into slots at front of firebox and resting opposite end on pins in
back of firebox.
Back of firebox
Front of firebox
Pin
23
