PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
Key Qty Description
A 1 FIREBOX
B 1 IGNITOR
C 1 BURNER
D 1 COLLECTOR/ ELECTRODE ASSY
E 1 LID
F 1 LOGO PLATE
G 1 LEFT SIDE SHELF F/ SB
H 1 RIGHT SIDE SHELF
I 1 TANK RETAINER
J 1 MOUNTING BRACKET, F/ SIDE SHELF, (RF/LB)
K 1 MOUNTING BRACKET, F/ SIDE SHELF, (LF/RB)
L 1 MOUNTING BRACKET, F/ PLASTIC SIDE SHELF,
(LF/RB)
M 1 MOUNTING BRACKET, F/ PLASTIC SIDE SHELF,
(RF/LB)
N 2 CART LEG,UPPER
O 1 SIDE BRACE
P 1 RIGHT FRONT LEG,CURVED
Q 1 RIGHT BACK LEG,STRAIGHT
R 1 LEFT BACK LEG,STRAIGHT
S 1 LEFT FRONT LEG,CURVED
T 2 BACK BRACE
U 2 SUPPORT BRACKET
V 1 LEFT FIREBOX SUPPORT
W 1 RIGHT FIREBOX SUPPORT
X 1 VALVE HOSE REGULATOR ASSEMBLY
Y 1 CONTROL PANEL
Z 1 FRONT PANEL
AA 1 CONDIMENT BASKET
BB 1 AXLE ROD
CC 2 LEG EXTENDER
DD 3 TANK EXCLUSION WIRE
EE 1 HEAT SHIELD
FF 1 COOKING GRATE
GG 1 SWINGAWAY GRID
HH 1 SIDEBURNER GRATE
II 1 SIDEBURNER
JJ 1 ELECTRODE, F/ SB
KK 1 DRIP PAN
Key Qty Description
LL 2 WHEEL
MM 3 KNOB
NN 2 LOWER HINGE
OO 2 UPPER HINGE
PP 1 HANDLE
QQ 1 GREASE CUP
RR 1 GREASE CUP CLIP
SS 1 HEAT TENT
TT 1 MATCH HOLDER
… 1 HARDWARE PACK
… 1
ASSY INSTRUCTION, ENGLISH
… 1
RETAINER CLIP
NOT Pictured
