Char-Broil MASTERFLAME 2 - Cleaning Lava Rock Burner Assembly

Cleaning
Lava Rock BurnerAssembly
1. Turn
gas
off at control knob(s) and LP
tank.
2. Remove
cooking
grate.
Discard
used lava rock, remove fire
?
4
5
grate.
Remove
scale fiom
fire
grate,
replace
grate
if
necessary,
Remove
can from
grease
clip.
Beneath
console
disconnect short ignitor wre
from ignitor
(A).
Remove screw
holding collector box
(B).
Note
which
hole on
collector box used
for attachinq to burner. Remove
collector
box,
clean ceramic
portion
of electrode wth
rubbing
alcohol and
cloth.
Under
console
disengage burner springs from
burner
tubes
(C).
Do not remove springs
from valve.
Slide burner
backwards, lift
up
and
out of
grill
(D).
Clean outside
of burner wth soap
and
water. Lay
burner upside down
on flat
surface,
insert
garden
hose to force water
through
tubes. Make
sure water comes out
of all burner
holes. Open
clogged holes
with
a thin wire Shake
out excess water
and
examine holes.
Due to normal wear
Collector Box
oT
Burner attached
to
Valve
\_l
Burner
Spring
Spring
Round end
to ignitor
and
corrosion
some holes may
become enlarged
lf any large
cracks or holes
are found replace burner
lf
grill
is to be stored,
coat burner lightly with
cooking
oil. Wrap in
protective
cover to keep
insects
out. lf not
storing
grill,
angle
burner
tubes
back into
grill
boftom
(D).
Valve
openings
must fit inside
burner tubes
After
cleaning,
insert wre and
eleckode into hole
in
grill
bottom
(A)
Reattach collector
box to burner
with
screw
(B).
Be sure
to use correct hole.
Place
ends of
springs into holes
on undersides
of burner
tubes
as before
(C)
to secure burner.
VERY
IMPORTANT:
Bumer tubes
must
engage
valve
openings
as shown
(E).
Note
non-engagement
(F).
Reattach
round
end of ignitor wire
to ignitor
a,
a,
10
11
tt Reposition
fire
grate
Place
lava rock onto fire
grate
(do
not
layer
or stack lava
rock
-
use
just
enough to
cover fire
grate
surface).
13
Reposition
cooking
grates
and reattach
clean can to
grease
clip
14
Before
cooking
again
on
grill
follow Burner
Flame Check.
