CAUTION
FACT: Sometimes spiders and other small insects climb into
the burner tubes attached to the burners. The spiders spin
webs, build nests and lay eggs. The webs or nests
can be very small, but they are very strong
and can block the flow of gas. Clean
burners prior to use after storing, at the
beginning of grilling season or after a period
of one month not being used.
NATURAL HAZARD • SPIDERS
Spider guards are on the air intakes in an effort to reduce this
problem, but it will not eliminate it! An obstruction can result
in a "flashback" (a fire in the burner tubes). The grill may still
light, but the obstruction does not allow full gas flow to the
burners.
Smell gas.
Burner(s) will not light.
A small yellow flame from burner (should be blue).
Fire coming from around or behind control knob.
Follow the “ ” instructions.
Clean burners often. Use a 12” pipe cleaner to clean out the
burner tubes. You may also force a stream of water from a
hose nozzle through burner tubes to clean them.
IF YOU EXPERIENCE THE FOLLOWING:
1.
2.
3.
4.
STOP!
Immediately turn off gas at gas source!
SOLUTION:
Wait for grill to cool.
Cleaning The Burner Assembly
Cleaning The Burner Assembly
Follow these instructions to clean and/or replace parts of burner
assembly or if you have trouble igniting grill.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Refer to illustration
on following page.
Turn gas off at control knobs and gas source.
Remove cooking grate and V-Bar.
Under grill remove soup can, disconnect ignitor wire (A) and
clips from burner (B). To remove clips pull down on large end
of clip attached to the valve, turn away from valve, rotate
upward and remove small end of clip from burner tube.
Inside grill remove burner assembly (C), clean ceramic
portion of electrode with rubbing alcohol and a swab.
Clean outside of burner with soap and water. Lay burner
upside down on flat surface, insert garden hose to force
water through tubes. Make sure water comes out of all
burner holes. Open clogged holes with a thin wire. Shake
out excess water and examine holes. Due to normal wear
and corrosion some holes may become enlarged. If any
large cracks or holes are found replace burner.
If grill is to be stored, coat burner lightly with cooking oil.
Wrap in protective cover to keep insects out.
If not storing grill after cleaning, replace burner into grill
bottom (C).
To reattach clips hold large curved end away from burner
tube, insert small curved end into hole under burner tubes,
turn clip towards valve, snap into place.
Reattach ignitor wire to ignitor (A).
Reposition v-bar and cooking grate(s). Reattach clean can to
grease clip.
11. Before cooking again on grill, perform a and
.
VERY IMPORTANT: Clips must be attached correctly for
proper grill function (B).
“Leak Test”
“Burner Flame Check”
Storing Your Grill
• Clean cooking grates.
• Store in dry location.
• Cover grill if stored outdoors. Choose from a variety of grill
covers offered by manufacturer.
• Store grill indoors ONLY if gas source is disconnected.
• When removing grill from storage, follow “
” instructions before starting grill.
