4 • 463822004
PARTS LIST – Model No. 463822004
Key Qty. Description Part #
A 1 Lower SwingAway ....................4152125
B 1 Cooking Grate .......................4152741
C 1 Condiment Basket ....................4154269
D 1 Handle .............................4154474
E 2 Side Shelf...........................4154543
F 2 Wheel Assembly......................4310002
G 1 Upper SwingAway ....................4156449
H 1 Back Support Brace ...................4500250
I 1 VBar ..............................4500291
J 2 Leg Assembly........................4502097
K 1 Front Panel..........................4502232
L 1 Side Support Brace ...................4502373
M 4 #10x1/2”, T-20, Self-Tap Screw ..........4080043
N 2 Valve Clip ...........................4151043
O 1 Burner/Collector Assembly..............4505085
P 1 Control Panel Assembly ................4530174
Q 2 Control Knob ........................4154470
R 1 Grill Bottom..........................4580468
S 1 Grill Lid .............................4580190
T 1 Logo Plate ..........................4157147
U 1 Grease Clip .........................5156607
Key Qty. Description Part#
V 1 12’ Natural Gas Hose..................4158033
W 2 Leg Extender ........................4154540
1 Hardware Bag, Cart ...................4254079
2 Hardware Bag, Shelves ................4254050
Optional Assembly Hardware
We realize some customers prefer to use tools.
have been provided for you to use.
Optional hex
nuts
To Next Page
