3
Left side panel
Grill head
Right side panel
Regulator hose
Upper back panel
This step requires two people to lift and position grill head onto cart. Carefully lower the grill head onto the
cart, aligning slots at bottom of grill head with posts on cart side panels. Make sure the regulator hose is
hanging inside the cart.
4
On back of grill, place upper back panel between side panels. Secure upper back panel in lower holes, using one
1/4-20x1½” screw on each side.
1/4-20x1 ½"
screw
Slots at bottom
14
