Right side fascia
Right side shelf
#10x3/8" screw
5
1/4-20x1 ½"
screw
1/4-20x1 ½"
screw
Fiber
washer
Front brace
Hinge pin
Control panel
6
Attach right side fascia to right side shelf using two #10x3/8" screws.
Only right side shelf shown for assembly, install left side fascia to left side shelf in the same way.
Screwdriver must pass through holes on
the side shelf bracket.
Insert front brace under control panel and between cart panels. Make sure door hinge pin is on the top side and facing the
front. Secure front brace in upper holes using one 1/4-20x1½” screw and Fiber washer on each side. Secure front brace in
lower holes using one 1/4-20x1½” screw on each side,
