Char-Broil T-36D User Manual

Key Qty Description
A 1 FIREBOX
B 3 MAIN BURNER, F/ FIREBOX
C 1 ELECTRODE, F/ MAIN BURNER, 900MM WIRE
D 2 ELECTRODE, F/ MAIN BURNER, 600MM WIRE
E 2 CARRY OVER TUBE
F 1 TROUGH, FIREBOX
G 1
TOP LID
H 1 LOGO PLATE, TEMP GAUGE
I 1 IGNITER SWITCH MODULE
J 1 HANDLE, TOP LID
K 2 HANDLE END, F/ LID HANDLE
L 2 RUBBER BUMPER, ROUND, W/ HARDWARE, F/
TOP LID
M 4 RUBBER BUMPER, LID
N 1 HARDWARE FOR TOP LID
O 3 COOKING GRATE
P 1 WARMING GRID
Q 1 VALVE/ HOSE/ REGULATOR ASSEMBLY
R 1 CONTROL PANEL
S 1 ELECTRONIC IGNITION MODULE
T 1 BUTTON, F/ EI MODULE
U 4 BEZEL F/ KNOB
V 4 CONTROL KNOB
W 1 MATCH HOLDER
X 1 SIDE SHELF, LEFT
Y 1 FASCIA, F/ LEFT SIDE SHELF
Z 1 DRIP PAN, SIDEBURNER
AA 1 ELECTRODE, F/ SB
BB 1 SIDEBURNER
CC 1 SIDEBURNER GRATE
DD 1 SIDEBURNER LID
EE 1 ELECTRODE WIRE, SIDEBURNER
FF 1 SIDE SHELF, RIGHT
GG 1 FASCIA, F/ RIGHT SIDE SHELF
HH 1 CART LEFT SIDE PANEL
II 1 CART RIGHT SIDE PANEL
JJ 1 BOTTOM SHELF
KK 1 UPPER BACK PANEL
LL 1 LOWER BACK PANEL
Key Qty Description
MM 1 HEAT SHIELD, F/ TANK
NN 1 FRONT BRACE
OO 1 LEFT DOOR, NO HANDLE
PP 2 DOOR HANDLE
QQ 1 RIGHT DOOR, NO HANDLE
RR 1 GROMMET
SS 1 TANK SCREW, F/ BOTTOM SHELF
TT 2 CASTER, LOCKING
UU 2 CASTER, FIXED
NOT Pictured
… 1 CASTER PIN
… 2 DOOR MAGNET
… 1 HARDWARE PACK
… 1 ASSEMBLY MANUAL, ENGLISH
… 1 ASSEMBLY MANUAL, FRENCH
PARTS LIST
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.
11

Char-Broil T-36D Specifications

General

Brand	Char-Broil
Model	T-36D
Category	Grill
Language	English
