Illustrations & Parts Listing Product Manual - Perma-Cyl
®
w/ FlexFill™ Piping Option
Item PN Description Item PN Description
BD-1 11671281 RPD ASSY INLINE 1/2MPT 375 PSI RV-4 1812702 RV BRS 1/4MPT 550 PSI
BD-1 11526569 RPD ASSY INLINE 1/2MPT 525 PSI RV-5 1810702 RV BRS 1/4MPT 550 PSI
CV-1 11051090 VALVE CHECK BRS 1/2FPTX1/2 FPT V-1 10502848 VALVE SHUTOFF BRZ 1/2FPT SHORT
Ll-1 20910598 CYL-TEL GEN 5 0-200”H
2
O V-2 11905999 VALVE SHUTOFF 1/4FPT
Ll-1 20923162 DIFF PG 4.5” 0-100” H
2
O VITON (O
2
,
N
2
)
V-3 11905999 VALVE SHUTOFF 1/4FPT
Ll-1 20909588 DIFF PG 4.5” 0-150” H
2
O VITON (Ar) V-4 11625639 VALVE GLOBE BRS 1/2FPT EX STEM
PI-1 20827654 PG 2-1/2” 0-600PSI/BAR 1/8MPT V-5 10616790 VALVE GLOBE BRS 1/2NPT SCRD
*R-1 11501177 REGULATOR .250FPT @ 140 PSI V-6 10616790 VALVE GLOBE BRS 1/2NPT SCRD
*R-1 20885664 REGULATOR .250FPT @ 325 PSI V-7 10907239 VALVE NEEDLE BRS 1/4MPT(ANGLE)
*R-2 11779806 REGULATOR .500FPT @ 125 PSI V-8 11773885 VALVE BALL DIV SS 1/2NPT
*R-2 11690211 REGULATOR .500FPT @ 300 PSI V-9 11905956 VALVE BRS SH 3/8FPTX3/8 SCH 10
RV-1 1812702 RV BRS 1/4MPT 550 PSI V-10 11905999 VALVE SHUTOFF 1/4FPT
*RV-2 11488574 RV BRS 1/2MPT 250 PSI V-11 20683719 VALVE 4-WAY BRS 1/8 FPT
*RV-2 20599868 RV BRS 1/2MPT 350 PSI V-12 11905999 VALVE SHUTOFF 1/4FPT
RV-3 1812702 RV BRS 1/4MPT 550 PSI V-13 11905999 VALVE SHUTOFF 1/4FPT
*Part numbers are dependent on the plumbing option kit chosen for the vessel.
