13
REPLACEMENT PARTS
Hydrocollator
®
Heating Units
Model M-2 – Standard
Cat. No. – 2402C w/packs
Key* Part Description Part No.
1 Lid 22297
2 Lid Hinge Rod Nuts (2 each) 21737
4 Element, Heating 120 Volt, 1000 Watt 10630
6 Hydraulic Thermostat** 10631
10 Power Cord 72453
11 IEC Connector 89790
12 Cover, Junction Box (J-Box) 22087
14 Pilot Lamp, Red 22149
15 Pilot Lamp, Clear 22148
16 Lid Hinge Rod 22303
17 Lid Knob/Handle 21025
18 Handle, Side 20237
19 Caster, 3-inch 21259
23 Drain, Copper Tube Part A 21286
24 Fuses 15 amp (2 each) tba
25 Thermostat Low Water Kit*** 20548
26 Fuse Block tba
27 Wiring (Internal) Harness 61579
28 Stainless, Wire Rack 22304
29 Drain Valve, Ball - 1/2 in Replacement 21085
30 Drain, Hose, Bib 23392
31 Replacement Tank M-2 56314
32 M-2 Outer Jacket 22421
33 Handle, Lid Kit**** 22171
* Key numbers refer to Nomenclature section (pages 6 and 7)
** Includes thermostat, gasket, 1/2-20 brass nut, 6-32x3/16 screw, and brackets (2) to hold
thermostats to heating element
*** Includes gasket, thermostat, and 1/2-20 brass nut
**** Includes decorative handle, 10-32 brass acorn nut, 10-32X2 screw, logo decal, & plastic washer
