Chattanooga hydrocollator - Replacement Parts (E-1 Model); E-1 Model Part List; E-1 Model Part Key

18
REPLACEMENT PARTS
Hydrocollator
®
Heating Units
Model E-1 – Standard
Cat. No. – 2102C w/packs
Key* Part Description Part No.
1 Lid 21004
2 Lid Hinge Rod Nuts (2 required) 21737
4 Element, Heating 120 Volt, 1000 Watt 21007
6 Hydraulic Thermostat** 10631
10 Power Cord 72453
11 IEC Connector 89790
12 Junction Box Cover 21005
14 Pilot Lamp, Red 22149
15 Pilot Lamp, Clear 22148
16 Lid Hinge Rod 22668
17 Handle, Lid 21025
18 Handle, Side Kit*** 21994
24 Fuses 15 amp (2 each) tba
25 Thermostat Low Water Kit**** 20548
26 Fuse Block tba
27 Wiring (Internal) Harness 61579
28 Rack, Stainless Steel 21062
* Key numbers refer to Nomenclature section (pages 6 and 7)
** Includes thermostat, gasket, 1/2-20 brass nut, screw 6-32x3/16, and brackets (2) to hold
thermostats to heating element
*** Includes 10-24X3/8 screw, E-1 side handle, nylon washer, 10-32 brass acorn nut, 10-32X1/4
screw, and handle adapter
**** Includes gasket, thermostat, and 1/2-20 brass nut
