7
일반 사양
Digital Display : 3¾ digit LCD display with maximum
reading 3999
Analog Display : 40 segmants fast analog bar-graph
Sampling Rate : Numeric -2times/sec,
Bar-graph - 20times/sec
Polarity : When negative signal in apply to the
tester, " " will show.
Over Load : When the signal larger than the
maximum will be show " ".
Battery discharge indication : " " mark indication
Auto power off : 30 minutes
Power supply : NEDA 1604 9V or 6F22 9V×1pc
Clamp Jaw size : 55mm(TK-2000AD), 42mm(TK-1000A)
Dimension (L X W X H) : 249x85x42mm(TK-2000AD),
230x65x42mm(TK-1000A)
Weight : 375g (include battery)
Accessories : Instruction manual, Carring case,
Test leads
2. General Specifications
OL
OL
표시화면 : 3¾ digit, 최대 3999, 자동 극성 전환
바 그래프 : 40 segment
속 도 : 숫자 --- 2회/초, 바 그래프 --- 20회/초
자동 전원 잠금 : 30분
과 입력 지시 : " "표시
저전압 경고 : " " 표시
전 원 : NEDA 1604 9V 또는 6F22 9V --- 1개
크램프 코아 : 55mm(TK-2000AD), 42mm(TK-1000A)
크기 (L x W x H) : 249x85x42mm(TK-2000AD),
230x65x42mm(TK-1000A)
중 량 : 약 375g (건전지 포함)
부속품 : 사용설명서, 소프트 케이스, 테스트 리드
8
The accuracy specification is defined as
±% reading ±digits
At 23℃ ±5℃, 80%RH
3. Measuring Specification(측정 사양)
DC Current (Auto range) ▶TK-2000AD
AC Current (40A Manual range, 1000A Auto range)
▶TK-1000A
AC Voltage (Auto range)
Range Resolution Accuracy Input Max
400A
2000A
0.1A
1A
±2%±5dgt
±2%±5dgt
2000A
※Response time : 5 second max. to rated accuracy within selected
range.(5초 이내 측정 요망)
AC Current (Auto range) ▶TK-2000AD
Range Resolution Accuracy Input Max
400A
2000A
0.1A
1A
±2%±5dgt
±2%±5dgt
2000A
Band Width
50Hz~500Hz
Range Resolution Accuracy Input Max
40A
1000A
10mA
100mA
1A
±1.5%±5dgt
±2%±5dgt
±2%±5dgt
1000A
Band Width
50Hz~500Hz
400A
1000A
Range Resolution Accuracy
Overload Protection
4V
40V
400V
600V
1mV
10mV
100mV
1V
±1.2%±4dgt
600Vrms
Input Impedance
10MΩ
※Response time : 5 second max. to rated accuracy within selected
range.(5초 이내 측정 요망)
※Response time : 5 second max. to rated accuracy within selected
range.(5초 이내 측정 요망)
