Chekman TK-1000A - Panel Description

9
DC Voltage (Auto range)
Range Resolution Accuracy
Overload Protection
400mV
4V
40V
400V
600V
0.1mV
1mV
10mV
100mV
1V
±1%±2dgt
600Vrms
Input Impedance
10MΩ
Frequency (Hz, Auto range)
Range Resolution Accuracy
Overload Protection
4KHz
40KHz
400KHz
4MHz
10MHz
1Hz
10Hz
100Hz
1KHz
10KHz
±0.3%±3dgt
600Vrms
4Vrms
Band Width
15Vrms
Resistance ( , Auto range)
Range Resolution Accuracy
Overload Protection
400Ω
4KΩ
40KΩ
400KΩ
4MΩ
40MΩ
0.1Ω
1Ω
10Ω
100Ω
1KΩ
10KΩ
±1%±2dgt
600Vrms
Max test voltage
-0.5VDC
±3%±5dgt
-1.5VDC
Ω
Continuity( )
Range Active Region
Overload Protection
400Ω ＜40Ω
1.5VDC
600Vrms
Max test voltage
10
4. Panel Description(각부명칭)
4-1. Clamp Core (클램프 코아)
Ω
MAN MAX MIN
MK
Hz
H
mAV
300 10 20
H
HOLD
MAX/MIN
RANGE
COM
CAT.
Ω
V
MAX
600V
Hz
Ω
V
Hz
1000A
40A
OFF
V
Clamp Core
클램프 코아
HOLD switch
홀드 스위치
Function
기능 스위치
switch
RANGE
레인지 스위치
switch
Display
표시화면
Measuring input+
입력단자+
TK-1000A:
MAX/MIN switch
최대 최소값 스위치/
TK- 000A :2 D
ZERO switch
영점조정 스위치
Measuring input-
입력단자-
