Chenbro RM23608 - Buzzer Code; IPMI Interface - I C Address Setting

Chenbro Storage Chassis
8-Port 12Gbps Mini-SAS HD Backplane User Manual
Http://www.chenbro.com
1
1
Buzzer Code
Buzzer code allows user to identify the issue by the way it sound, user may disable the sound by ※DIP
switch
Event
Tone
Fan alarm
One long beeps sound
Temperature alarm
Two short beeps sound
※Refer to DIP switch
IPMI interface – I
2
C Address setting
Backplane I2C address can be changed by jumper setting table as below, the default setting is 0xC0
JP02
JP03
Address (8 bits)
JP1-2
JP1-2
0xC0
JP2-3
JP1-2
0xC4
JP1-2
JP2-3
0xC8
JP2-3
JP2-3
0xCC
