7 Installation of the software
7.1 Cherry Tools
Install the Cherry Tools software.
You can configure all the functions of the keyboard
with the Designer found within the software.
The following functions are supported:
• Configuring the keyboard/keys/barcode
decoder/magnetic card reader
• Updating the country-specific settings (country
table)
• Updating the firmware
• Displaying the key configuration (KeyViewer)
Operation instructions are included in the direct
help for the Cherry Tools software. It offers you
information where you need it and can be called up
with F1.
Latest software version on the internet
The software is subject to constant development.
The latest version is available on the Internet
under: http://support.cherry.de
1 Insert your CD in the CD-ROM drive.
The CD-ROM starts automatically.
2 If the CD-ROM does not start automatically,
double click on the CD-ROM drive in
Windows-Explorer and then on the file
autostart.exe.
3 Follow the installation instructions on the screen.
7.2 Restoring the basic setting
1 Open the Cherry Tools software.
2 Read out the active configuration of the
keyboard.
3 Select Restore standard values in the menu
bar under Configuration.
4 Save this configuration to the keyboard by
clicking on the Activate button.
The basic keyboard setting is restored.
7.3 Cherry UPOS support
The standards OPOS and JavaPOS are combined
and constantly developed (www.nrf-arts.org) under
the umbrella of the UPOS (Unified Point of Sale)
specification.
If you use applications which access the keyboard
or the magnetic card reader via OPOS or
JavaPOS:
Windows operating system
¾ Install the software Cherry OPOS Support or
Cherry JPOS Support.
Linux operating system
¾ Use the installation scripts for JavaPOS support
on the CD-ROM.
8 Manual configuration
(all models except MY 8300)
You can also configure the keyboard manually
without installing any software. Physical
configuration is always used in this case.
8.1 Configuring magnetic card readers,
barcode readers and general
keyboard functions
1 Launch a text editor such as Notepad or Word
so that you can keep track of any input or output
on the monitor.
2 Only use the number keys on the keyboard
block, not those on the numerical keypad.
3 Select configuration mode by pressing the six
modifier keys simultaneously for at least three
seconds: left Shift key, left Ctrl key,
left Alt key, right Shift key, right Ctrl key,
right Alt Gr key.
A double beep is emitted to confirm that you are
now in configuration mode. Provided you have
activated this option, MENU ENTRY is displayed
in the editor.
4 To configure the magnetic card reader, barcode
decoder or general keyboard functions, enter
the corresponding programming code as
necessary (see "Codes for manual
programming" on page 15). Each code consists
of at least three key presses.
