4.1 Connecting the barcode scanner
1 Shut down the system before plugging in the
barcode scanner.
2 Only connect barcode scanners with a
maximum power requirement of 150 mA. (This
maximum value applies even when connecting
more than one barcode scanner.)
3 Observe the safety regulations specified by the
manufacturer of the barcode scanner. The basic
setting for a connected barcode scanner is
"laser emulation."
The data is converted into corresponding character
strings and is transferred to the system via the
PS/2 port.
An audible tone (beep) confirms a valid reading.
You can configure the tone using the
Cherry Tools software: Switch the valid reading
signal on/off or set to continuous.
5 Touchpad (Model MX 8100 only)
The touchpad replaces the mouse. You can move
the mouse cursor with your finger, and select and
drag objects.
Move the mouse cursor
¾ Move your finger across the touchpad.
Double-click
¾ Touch the touchpad twice in quick succession.
6 Configuration
6.1 Header and terminator
The header and terminator identify the start and
finish of the transfer of magnetic card or barcode
data. The header/terminator sequence is inserted
before/after the actual data.
6.2 Physical and virtual configuration
You can configure the keyboard physically or
virtually.
Advantages of physical configuration:
• Once the configuration has been loaded to the
keyboard, it is stored there indefinitely
• The keyboard can be used on other systems
with the appropriate settings
• Functions independently from the operating
system
• No additional software support/drivers required
Advantages of virtual configuration:
• The configuration file is stored on the respective
system
• The configuration is executed in the form of a
software macro
• Additional functionality
6.3 Storage Capacity
All models except MY 8300
MY 8300
Physical
configuration
Virtual
configuration
Keys Max. 16
characters per
key
Approx. 2000
characters per
key
Header Max. 16
characters per
track
Not possible
Terminator Max. 16
characters per
track
Not possible
Physical
configuration
Virtual
configuration
Program-
mable
function
keys (PF)
Max. 64
characters per
key per layer.
Max. 10 layers
(240 configuration
spaces)
Approx. 2000
characters per
key at layer 1.
(Only layer 1 can
be configured
virtually.)
