Cherry MY 7000 - Technical Data

7
13 Technical data
13.1 Overview
13.2 Keyboard
13.3 Magnetic card reader
Model
(item no.)
Mag-
netic
card
reader
Exten-
ded key
layout
Touch-
pad
Blank
keys
which
can be
labeled
MY 7000
(G81-7000)
X
MX 8000
(G80-8200)
XX X
MY 8000
(G81-8000)
X
MX 8100
(G80-8113)
XXXX
MY 8300
(G81-8308)
XX
Designation Value
Port PS/2 plug
Power supply +5 V/DC ±5 % SELV
Current consumption
(without barcode
reader)
Max. 100 mA
Storage temperature
range
–20 °C to +60 °C
Operating temperature
range
0 °C to +50 °C
Designation Value
Tracks Max. 3
Reading speed 3 to 125 ips at 75 bpi
3 to 50 ips at 210 bpi
Standards ISO 7811/-12, JIS 1,
AAMVA, Gemini
13.4 Barcode decoder
The following barcodes are automatically
recognized and decoded:
•EAN code
• UPC code
• Code39
• Code 93
• Code128
• Codabar
• Code 11
• Code 16K
• Interleaved 2/5 code
• Industrial 2/5 code
• Matrix 2/5 code
•Plessey
• MSI (Modified Plessey)
Designation Value
Reading speed 3 to 400 ips
