CHERY A21 SERVICE MANUAL MECHANISM OF 2.0NALC ENGINE
12
timing belt” for details).
2) Loosen the central bolt of tension pulley
and remove the timing belt.
2.3 Inspection
Check the timing belt carefully; replace the
parts if any following situation occurs.
(1) Chap of back-side rubber
(2) Chap of dedendum, chap of separated
cord fabric.
(3) Wearing, gear missing and incomplete
gear of cord fabric.
(4) Abnormal wearing of belt flank.
Replace the belt as any following situation occurs, even though abrasion cannot be found
directly.
1) The water pump leaks water out, and requires continuing infusion.
2) If the belt is spotted with much oil stains, and the rubber may be damaged due to
expansion, you should replace the belt.
Chap
Chap
