CHERY A21 SERVICE MANUAL MECHANISM OF 2.0NALC ENGINE
41
6.2 Installation
1) Clean the oil seal seat ring. Clean the oil
seal seat ring with clean oiled gauze.
2) Spread the oil at the lip of crankshaft
front oil seal.
Enclose the guide sleeve of crankshaft oil
seal, special tool, with that oil seal. Then
press it into oil seal seat ring.
3) Mount the flywheel and the clutch
pressure plate, and then mount the
engine on the vehicle.
Torque:25±5N.M, then screw 30°±5°.
7. Replace crankshaft and thrust washer
7.1 Needed tools and auxiliary materials
A set of open end wrenches, a set of sleeve
tools, a small hoist, Le Tai glue, Engine oil,
feeler gauge, feeler gauge, micrometer gauge.
7.2 Process of Removal
1) Suspend the engine assembly from
vehicle (See “suspending of engine
assembly” for details）.
2) Drain out the engine oil.
3) Remove the timing belt (see “replace
timing belt” for details).
To Next Page
