PARTS LIST - GENERATOR
NOTE:
Some parts are listed and shown for illustration purposes only, and are not
available individually as replacement parts.
Part Description Qty.
1 Bolt w/Lock Washer (M6x12) 4
2 Engine Switch 1
3 Circuit Breaker (30 Amp) 1
4 Control Panel 1
5 Circuit Breaker (20 Amp) 4
6 Bolt (M5x12) 2
7 Voltmeter 2
8 Outlet Socket (120V) 2
9 Grounding Terminal 1
10 Outlet Socket (120V) 1
10B Outlet Socket (240V/120V) 1
11 Shock Absorber 4
12 Bolt (M5x215) 2
13 Lock Washer Nut (M8) 12
14 Stator Cover 1
15 Alternator Back Cover 1
16 Automatic Voltage Regulator 1
17 Bolt (M5x12) 7
18 Rectier 1
19 Bolt (M5x20) 2
20 Cable Sheath 1
21 Carbon Brush 1
22 Bolt (M10x1.25x265) 1
23 Bolt (M6x180) 4
24 Bolt (M5x20) 4
25 Connection Board 1
26 Nut (M5) 4
27 Stator 1
28 Rotor 1
29 Cooling Fan 1
30 Heat Insulation Board Assy. 1
31 Fuel Tank 1
32 Fuel Filter 1
33 Seal Ring 1
34 Fuel Tank Cap 1
37 Lock Washer Bolt (M6x30) 4
Part Description Qty.
38 Spacer 4
39 Rub Washer 4
40 Bushing 4
41 Fuel Valve 1
42 Frame 1
43 Switch Box Cover 1
44 Battery Guard Plate 1
45 Battery (Not Included) 1
46 Bolt w/Lock Washer (M6x12) 2
47 Battery Bracket 1
48 Battery Tray 1
49 Axle 1
50 Wheel 2
51 Pin 4
52 Bolt (M8x20) 8
53 Axle Bracket 2
54 Shock Absorbing Foot 2
55 Bolt (M8x25) 2
56 Bracket 2
57 Nut (M8) 2
58 Connection Board (Mufer) 1
59 Bolt (M8x20) 4
60 Bolt w/Lock Washer (M6x12) 8
61 Handle 2
62 Bolt (M8x45) 2
63 Pin (8x45) 2
64 Bolt (M6x45) 4
65 Link 2
66 Washer (M6) 4
67 Lock Washer 4
68 Nut (M6) 4
69 Nut (M8) 2
70 Pin (2x20) 2
