Page 22SKU 66604 For technical questions, please call 1-800-444-3353.
Part Description Qty.
1A Mufer 1
2A Cylinder Head Bolt 4
3A Cylinder Head Cover Bolt 4
4A Cylinder Head Cover 1
5A Lock Nut 2
6A Adjusting Screw 2
7A Rocker Arm 3
8A Rocker Arm Bolt 2
9A Valve Push Rod Guide Board 1
10A Valve Push Rod 2
11A Cylinder Head 1
12A Carburetor Shield 1
13A Carburetor Packing 1
14A Carburetor Assy. 1
15A Air Cleaner Case 1
16A Air Cleaner Seal 1
17A Bolt (M6) 4
18A Air Cleaner Cover 1
19A Air Cleaner Element 1
20A Air Cleaner Separator 1
21A Choke Lever 1
22A Carburetor Packing (II) 1
23A Stud Bolt (M6x109) 2
24A Intake Valve 1
25A Exhaust Valve 1
26A Cylinder Head Gasket 1
27A Exhaust Pipe Stud 2
28A Spark Plug 1
29A Valve Guide 2
30A Valve Spring 2
31A Rocker Shaft Circlip 2
32A Anti-Wear Valve Stem Protector 2
33A Cylinder Head Cover Packing 1
34A Governor Spring 1
35A Bolt 1
36A High Tension Line 1
37A Ignition Coil 1
38A Nut (Special 14mm) 1
Part Description Qty.
39A Starter Ratchet Spring 2
40A Starter Rope 1
41A Starter Handle 1
42A Recoil Starter 1
43A Spiral Spring 1
44A Starter Wheel 1
45A Circlip 1
46A Starter Ratchet 2
47A Friction Plate Screw 1
48A Cover 1
49A Starter Pulley 1
50A Cooling Fan 1
51A Flywheel Magneto 1
52A Cylinder Block 1
53A Speed Control Lever 1
54A Governor Arm 1
55A Governor Spring 1
56A Governor Support 1
57A Bolt (M6x15) 2
58A Oil Alert Nut 1
59A Plug (M10x15) 2
60A Plug Washer 2
61A Oil Alert 1
62A Bolt (M6) 2
63A Crankshaft 1
64A Crankshaft Gear 1
65A Oil Dipstick 2
66A Oil Dipstick Seal Ring 2
68A Bolt (M8x35) 1
69A Gear Case Packing 6
70A Bearing 2
71A Camshaft Assy. 1
72A Locating Pin 4
73A Oil Seal 2
74A Connecting Rod Bolt 2
75A Connecting Rod Cap 1
76A Connecting Rod 1
77A Piston 1
PARTS LIST - ENGINE
