Page 14SKU 66604 For technical questions, please call 1-800-444-3353.
THIS UNIT CAN POWER THE FOLLOWING ITEMS
Note: Wattages listed above are estimates. Check nameplate wattages on all loads
before connecting to Generator.
OPERATING INSTRUCTIONS
Check to make sure the Engine Switch (2) is in its 1. “OFF” position.
(See Figure A.)
IMPORTANT: 2. Make sure to unplug any load from the Generator before starting to
prevent permanent damage to any appliances, tools, or equipment.
Turn the Engine Fuel Valve (41) to its3. “OPEN” position. Then turn the Engine
Choke Lever (21A) to its “CHOKE” position. No choke is required if the Engine is
warm. Make sure the Choke Lever is in the “RUN” position when starting a warm
Engine. (See Figure F.)
To start the Engine, using the Battery (45) for cranking power, insert the Engine 4.
Switch Key into the Engine Switch (2). Then turn the Key to the “START” position.
NOTE: To prolong Starter life, use short starting cycles (5 seconds maximum).
Then wait one minute before attempting to start again. (See Figure A.)
To start the Engine manually, using the Starter Handle (41A), insert the Engine 5.
Switch Key and turn the Key to its “RUN” position. Grasp the Starter Handle, and
pull slowly until resistance is felt. Allow the Starter Rope to rewind slowly. Then,
pull the Starter Handle with a rapid, full arm stroke. Allow the Rope to rewind
slowly. If necessary, repeat this procedure until the Engine starts.
When the Engine starts, slowly move the Choke Lever (21A) to its 6. “RUN” position.
(See Figure F.)
IMPORTANT: 7. Allow the Generator to run at no load for ve minutes after each
start-up so that the Engine and Generator can stabilize.
ITEM RUNNING
WATTS
START-UP
WATTS
1 HP Air Compressor 1600 4500
Belt Sander 1200 2400
Pressure Washer 1200 3600
Refrigerator/Freezer 700 2200
1/2 HP Sump Pump 1050 2150
1/2 HP Well Pump 1000 2100
Miter Saw 1650 3000
1-1/2 HP Capacitor Start & Run
Motor
1400 3100
Central AC-32, 000 BTU 5000 6500
10” Table Saw 1800 4500
