3.2 Specifications
1) Display: Backlit, 128 x 64 pixel display with contrast adjustment
2) Operating Temperature: 0 to 60°C (32 to 140 F°)
3) Storage Temperature: -20 to 70°C (-4 to 158 F°)
4) External Power: 8.0 to 18.0 V power provided via vehicle battery
5) Internal Power: 9V cell battery
6) Dimensions:
Length Width Height
178 mm (7.00”) 95 mm (3.74”) 35 mm (1.38”)
7) NW: 0.38kg (0.84lb), GW: 0.55 kg(1.21lb)
3.3 Accessories Included
1) User’s Manual -- Instructions on tool operations.
2) CD -- Includes user’s manual, DTC lookup software, and etc.
3) OBD2 cable -- Provides power to tool and communicates between
tool and vehicle
4) USB cable -- Used to upgrade the scan tool, and to print retrieved
data.
5) Carry case -- A nylon case to store the scan tool when not in use.
6) Cell battery -- Supplies power to the scan tool when
disconnected from vehicle DLC.
3.4 Navigation Characters
Characters used to help navigate the scan tool are:
1) “►” -- Indicates current selection.
2) “ ” -- A DOWN Arrow indicates additional information is
available on next screens.
3) “ ” -- An UP Arrow indicates additional information is available
on previous screens.
4) “$” -- Identifies the control module number from which data is
retrieved.
10
