CHICAGO 98614 - Viewing Freeze Frame Data

To Next Page

To Previous Page

Playback 6/16

DTC_CNT 6

FUELSYS1 OL

FUELSYS2 N/A

►LOAD_PCT (%) 0.0 ?

ETC(℃) -40

SHRTFT1(%) 0.0

5.4 Viewing Freeze Frame Data

1) To view freeze frame data, use UP/DOWN scroll button to select

View Freeze Frame from Diagnostic Menu and press ENTER

button.

...... ...Diagnostic Menu..... ........

4/11

Read Codes

Erase Codes

Live Data ?

►View Freeze Frame

I/M Readiness

O2 Monitor Test

2) Wait a few seconds while the scan tool validates the PID MAP.

….………View Freeze Frame…………

Reading PID.01

- Please Wait -

3) If retrieved information covers more than one screen, then a down

arrow will appear. Use DOWN scroll button, as necessary, until

all the data have been shown up.
