Rich-Lean Threshd (V)
5) Use UP/DOWN scroll button to view more screens of data if
an
or icon displays.
6) Press ESC button to return to the previous menus.
5.7 On-Board Monitor Test
The On-Board Monitor Test is useful after servicing or after
erasing a vehicle’s control module memory. The On-Board
Monitor Test for non-CAN-equipped vehicles retrieves and
displays test results for emission-related powertrain components
and systems that are not continuously monitored. The On-Board
Monitor Test for CAN-equipped vehicles retrieves and displays
test results for emission-related powertrain components and
systems that are and are not continuously monitored. Test and
components IDs are determined by the vehicle manufacturer.
1) Use UP/DOWN scroll button to select On-Board Mon. Test
from Diagnostic Menu and press ENTER button.
2) Wait a few seconds while the scan tool validates the PID MAP.
MOD: $11
MEAS: 0.580
MIN: 0.100
MAX: -----
