…………Custom Data Set……… ……..
6
■DTC_CNT #01
□FUELSYS1
■FUELSYS2 #02 ?
■LOAD_PCT(%) #03
□ETC(℃)
41
z You are allowed to pick up a maximum of 18 PIDs. If the
selected PIDs exceed 18, a “The selected data list is full!”
message displays on the screen.
z If you wish to deselect all marked items, press LEFT button.
z A message comes up to ask for your confirmation.
z If you decide to deselect these items, press ENTER; if you
decide not to, press ESC button, or use UP/DOWN button to
select NO and press ENTER to continue PID selections.
11) Use UP/DOWN scroll button to select a trigger mode and press
ENTER button.
………… Custom Data Set……………..
5
■DTC_CNT #01
□FUELSYS1
■FUELSYS2 #02 ?
■LOAD_PCT(%) #03
►□ETC(℉)
□SHRTFT1(%)
…… ….Deselect All…………………..
Deselect all
selected PIDs?
YES NO
►□SHRTFT1(%)
