Chigo 38B - 6. Parameters; Table 6-1: Specifications

9
6. Parameter
Table 6-1
Model
KFR-25GW/AGX1c
KFR-35GW/AGX1c KFR-51GW/BGX1c KFR-70GW/X1c
Power supply
Ph-V-Hz
220-240/50 220-240/50 220-240/50 220-240/50
Capacity W
2600/2780 3433/3590 5100 7000
Input W
928/865 1183/1120 1590 2300
Rated current A
4.1/4.0 5.2/5.1 6.8 10.3
Cooling
EER w/w.
2.8/3.2 2.90/3.2 3.21 3.043478261
Capacity w
2700/2780 3414/3680 5200 7500
Input W
812/770 1076/1020 1600 2330
Rated current A
3.6/3.5 4.8/4.7 6.9 10.4
Heating
COP w/w
3.30/3.61 3.17/3.6 3.25 3.21888412
Max. input consumption W
1250 2170 2300 3600
Max. current A
7 10.6 12.3 19.5
Model
PA108X1C-4DZDE PA140X2C-4FT PA200X2CS-4KU1 PA270X3CS-4MU2
Type
ROTAING ROTAING ROTAING ROTAING
Brand
TSHIBA TSHIBA TSHIBA TSHIBA
Capacity W
2570 3365 4890 6650
Input W
885±5℅ 1160±5℅ 1715 2270
Start electric current
A
21.7±10℅ 31.83 10.32
Rated current(RLA)/Locked
rotor Amp(LRA)
A
4.15±5℅ 5.4±5℅ 7.45
Thermal protector
B160-135-241E/MR
A13430-9087/
Outside sets
UP3-RE0596-T56/
Outside sets
UP3QE0391-T39/
Outside sets
Outside sets
Capacitor uF
25 35 45 50/400
Compressor
Refrigerant oil ml
ESTER OIL
VG74/350
ESTER OIL VG74.
750mi
Model YDK-16-4 YDK-16-4 YDK-16-4 YDK-38-4
Brand
W
35 35 45W 82
Capacitor
uF
1.2 1.2 1.2μF 3.5
Fan motor
Speed(hi/mi/lo)
r/min
1250/1050 /850 1250/1050 /850 1250/1050/850
1330/1200/1050
Fan motor diameter×height
mm
97X 633
97X 633 φ97×772 φ108×811
Air flow
m3/h
550/480/400 645/466/412/ 720 1050
Noise level
dB(A)
42.3/36.5/30.9 42.7/39.8/34.5 37-45 43-49
Dimension (W*H*D)
mm
790*270*180 790*270*180 940×270×180 1070×325×250
Packing (W*H*D)
mm
870*350*270 870*350*270 1005×335×260 1175×305×395
Indoor unit
Net/Gross weight
Kg
10/12 10/12 12.3/14 18/21
Model YDK-30-6 YDK-35-6A H YDK-38-6B YDK-60A-6F
Input
W
45 50 920 145
Capacitor
uF
2 2 2.5 4
Fan motor
Speed
r/min
890 / / 920 850
Fan motor diameter×height
mm
φ384×136 φ401X 115 Φ401×115 φ460χ180
Air flow
m3/h
Noise level
dB(A)
51.1/49 54/55 56 56
Outdoor uni
Dimension (W*H*D)
mm
700*225*500 795*255*540 795*255*540 875*315*680
