Chigo CCR-36CR1 User Manual

R410A50Hz Universal Outdoor Series Technical Manual 4 -way Cassette Indoor Unit
14
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Max
pressure
MPa 4 4 4 4 4 4 4
Refrigerant type
R410A
R410A
R410A
R410A
R410A
R410A
R410A
Refrigera
nt piping
Liquid side/Gas
side
mm
Φ6.35/Φ1
2.7
Φ6.35/Φ
12.7
Φ6.35/Φ1
2.7
Φ6.35/Φ
12.7
Φ6.35/Φ
12.7
Φ6.35/Φ
12.7
Φ6.35/Φ
12.7
Drainage pipe
mm
DN25
DN25
DN25
DN25
DN25
DN25
DN25
Standard controller Standard for remote controller(wired controller for option)
Operation temp
°C
16
～
32
16
～
32
16
～
32
16
～
32
16
～
32
16
～
32
16
～
32
Ambient
temp
cooling °C 18-50 18-50 18-50 18-50 18-50 18-50 18-50
heating °C -7～24 -7～24 -7～24 -7～24 -7～24 -7～24 -7～24
Application area m
2
15~25 20-35 20-35 20-35 20-35 20-35 20-35
Stuffing
Quantity(20'/40'/40'HQ)
set
120/240/2
70
120/240/
270
120/240/2
70
75/155/1
70
75/155/1
70
75/155/1
70
75/155/1
70
Model CCA-24HR1 CCA-24CR1 CCR-24HR1 CCR-24CR1
Indoor power supply V/Ph/Hz 220~240/1/50 220~240/1/50 220~240/1/50 220~240/1/50
Cooling
Capacity
Btu/h
24000
24000
24000
24000
KW
7.1
7.1
7.1
7.1
Input
W
150
150
150
150
Rated current A 0.7 0.7 0.7 0.7
EER
W/W
2.78
2.78
2.78
2.78
Heating
Capacity
Btu/h
26000
26000
KW
7.7
7.7
Input
W
150
150
Rated current A 0.7 0.7
COP
W/W
3.42
3.42
Indoor
fan motor
Model YDK-45Q-6P3 YDK-45Q-6P3 YDK-45Q-6P3
YDK-45Q-6P3
-1
Input
W
150
120
150
120
Capacitor
μF
3
3
3
3
Speed(Hi/Me/Lo
)
r/min 850/790/600 850/790/600 850/790/600 850/790/600
Indoor
coil
Number of rows
2
2
2
2
Tube pitch(a) x
row pitch(b)
mm 21×13.37 21×13.37 21×13.37 21×13.37
Fin spacing
mm
1.45
1.45
1.45
1.45
Fin type Hydrophilic Hydrophilic Hydrophilic Hydrophilic
Tube outside
dia. and type
mm
Ф7
Ф7
Ф7
Ф7
inner grooved inner grooved inner grooved inner grooved
Coil length x
height x width
mm
2000×168×26
.74
2000×168×26
.74
2000×168×26
.74
2000×168×26
.74
Number of circuits
8
8
8
8
