R410A50Hz Universal Outdoor Series Technical ManualFloor ceiling
94
GD Chigo Heating & Ventilation Equipment Co., Ltd.
Drainage pipe
mm
25
25
25
25
25
25
Standard controller Standard for remote controller(wired controller for option)
Opera
tion
temp
°C
16～32 16～32 16～32 16～32 16～32 16～32
Ambient temp
°C
-7
～
50
-7
～
50
-7
～
50
-7
～
50
-7
～
50
-7
～
50
Application area
m
2
20-35
20-35
28-50
28-50
40-70
40-70
Stuffing
Quantity(20'/40'/4
0'HQ)
set
132/270/30
6
132/270/30
6
75/165/189 75/165/189 75/165/189 75/165/189
Model CUA-48HR1 CUA-48CR1 CUA-60HR1 CUA-60CR1
Indoor power supply
V/Ph/
Hz
220~240V/1Ph/5
0Hz
220~240V/1Ph/5
0Hz
220~240V/1Ph/5
0Hz
220~240V/1Ph/5
0Hz
Cooling
Capacity
Btu/h
48000
48000
60000
60000
KW
14
14
16
16
Input
W
260
260
260
260
Rated current A 1.15 1.15 1.15 1.15
EER
W/W
2.66
2.66
2.68
2.68
Heating
Capacity
Btu/h
52000
60000
KW
15.2
16
Input
W
260
260
Rated current A 1.15 1.15
COP
W/W
2.84
2.64
Indoor
fan
motor
Model
YSK110-59LD-4P
17
+YSK110-59LD-4
P17
YSK110-59LD-4P
17
+YSK110-59LD-4
P17
YSK110-59LD-4P
17
+YSK110-59LD-4
P17
YSK110-59LD-4P
17
+YSK110-59LD-4
P17
Input
W
260
260
260
260
Capacitor
μF
3+3
3+3
3+3
3+3
Speed(Hi/Me/Lo
)
r/min 1310/1139/1016 1310/1139/1016 1310/1139/1016 1310/1139/1016
Indoor
coil
Number of rows
2
2
2
2
Fin spacing
mm
1.5
1.5
1.5
1.5
Fin type
Hydrophilic
Hydrophilic
Hydrophilic
Hydrophilic
Number of circuits
5
5
5
5
Indoor air flow(High speed) m
3
/h 2300 2300 2300 2300
Indoor noise level
dB(A)
57
57
57
57
Indoor
unit
Dimension(W*H
*D)
mm 1670×680×247 1670×680×247 1670×680×247 1670×680×247
Packing(W*H*D
)
mm 1750×770×330 1750×770×330 1750×770×330 1750×770×330
Net/Gross
weight
kg 47/54 47/54 47/54 47/54
Max
pressure
MPa 4.5 4.5 4.5 4.5
Refrigerant type
R410A
R410A
R410A
R410A
