Chigo CSQ4-300R User Manual

2. Specification
Model NO.
CSQ4-300R
CSQ4-350R
CSQ4-470R
Air flow (Hi-speed)
CFM
300
350
470
m3/h
500
600
800
Cooling Capacity (Hi-speed)
W
2800
3500
4500
Btu
9550
11940
15350
Heating Capacity (Hi-speed)
W
4200
5300
6800
Btu
14330
18080
23200
Noise (Hi-speed)
dB(A)
40
44
44
Water flow
m3/h
0.48
0.60
0.78
Water pressure drop
kPa
25
28
30
Indoor coil
Number Of Rows
2
2
2
Tube Pitch(A)x Row Pitch(B)
mm
25.4×22
21×12.7
21×12.7
Fin spacing
mm
1.55
Fin type
Hydrophilic aluminum
Tube Outside Dia.And type
mm
φ9.52, inner
grooved tube
φ7, inner
grooved tube
φ7, inner
grooved tube
Coil Dimension (L×H×W)
mm
425x203.2×22
435×210×25.4
435×210×25.4
Fan motor
type
Low noise 3-speed fan motor
Number
1
1
1
Input
W
43
64
65
Capacitor
μF
2
2
2.5
Indoor unit
Dimension (W×H×D)
mm
580×275×580
580×275×580
580×275×580
Packing (W×H×D)
mm
745×350×675
745×350×675
745×350×675
Net/Gross weight
Kg
22/24
22/24
22/24
plane
Dimension (W×H×D)
mm
650×30×650
650×30×650
650×30×650
Packing (W×H×D)
mm
710x120x710
710x120x710
710x120x710
Net/Gross weight
Kg
2.7/4
2.7/4
2.7/4
Control Mode
wired controller(optional),remote controller(standard)
Pipe
water-inlet pipe
mm
DN20
DN20
DN20
water-return pipe
mm
DN20
DN20
DN20
Condensation water-out let
pipe
mm
DN25
DN25
DN25
Remark: 1. All performance data above is based upon 0Pa ambient static pressure.
2. Cooling capacity test condition: air inlet Temp. : 27DB℃/19WB℃, water inlet Temp. 7℃, water Temp. difference
5℃.
3. Heating capacity test condition: Air inlet Temp. 21DB℃, water inlet Temp. 60 DB℃, water Temp. difference
5℃.
