CHIGO CAC FCU MCAC-VTSM-2008-09
Błąd! Nie można odnaleźć źródła odwołania.
● After tightening bolts, if there is still a slit between the ceiling and the panel, adjust the height of the unit
again (See the left one of Fig 14);
● If lifting and declining the unit and the length of drain pipe is not limited, you can adjust the height of
indoor unit through the opening at the four corners (See the right one of Fig 14)
D. First put the air grille onto the panel and then connect the leads of the swing motor and the control box
with the corresponding connectors on the main unit;
E. Install the air inlet grille contrary to the steps of removing it;
